Size chart for fitting. If this bike already feels right, find others with a similar riding position (size L). Category: mtb-xc.
| Size | Stack | Reach | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop |
|---|---|---|---|---|---|---|---|
| L | 607 mm | 474 mm | 66.5° | 75.5° | 432 mm | 1194 mm | 42 mm |
| M | 598 mm | 449 mm | 66.5° | 75.5° | 432 mm | 1167 mm | 42 mm |
| S | 589 mm | 424 mm | 66.5° | 75.5° | 432 mm | 1141 mm | 42 mm |
| XL | 621 mm | 499 mm | 66.5° | 75.5° | 432 mm | 1223 mm | 42 mm |
Closest matches to this riding position — free, no login.
Stack and reach describe the frame's cockpit envelope better than traditional seat-tube sizing. If you know your preferred stack/reach from a bike that already fits, search within a few millimeters first, then check head angle and chainstay for handling feel. See the glossary for stack, reach, and HTA.
