Size chart for fitting. If this bike already feels right, find others with a similar riding position (size 2XS). Category: cyclocross.
| Size | Stack | Reach | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop |
|---|---|---|---|---|---|---|---|
| 2XS | 519 mm | 369 mm | 70.5° | 74.0° | 425 mm | 1004 mm | 68 mm |
| L | 591 mm | 399 mm | 72.0° | 73.2° | 425 mm | 1045 mm | 66 mm |
| M | 571 mm | 392 mm | 72.0° | 73.5° | 425 mm | 1033 mm | 66 mm |
| S | 554 mm | 385 mm | 71.5° | 73.5° | 425 mm | 1023 mm | 68 mm |
| XL | 613 mm | 406 mm | 72.5° | 73.0° | 425 mm | 1057 mm | 66 mm |
| XS | 537 mm | 377 mm | 71.0° | 73.8° | 425 mm | 1013 mm | 68 mm |
Closest matches to this riding position — free, no login.
Stack and reach describe the frame's cockpit envelope better than traditional seat-tube sizing. If you know your preferred stack/reach from a bike that already fits, search within a few millimeters first, then check head angle and chainstay for handling feel. See the glossary for stack, reach, and HTA.
