Size chart for fitting. If this bike already feels right, find others with a similar riding position (size L). Category: mtb-enduro.
| Size | Stack | Reach | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop |
|---|---|---|---|---|---|---|---|
| L | 633 mm | 489 mm | 64.0° | 78.2° | 445 mm | 1282 mm | 25 mm |
| M | 624 mm | 469 mm | 64.0° | 78.0° | 445 mm | 1259 mm | 25 mm |
| XL | 642 mm | 509 mm | 64.0° | 78.4° | 445 mm | 1305 mm | 25 mm |
| XXL | 660 mm | 534 mm | 64.0° | 78.6° | 445 mm | 1337 mm | 25 mm |
Closest matches to this riding position — free, no login.
Stack and reach describe the frame's cockpit envelope better than traditional seat-tube sizing. If you know your preferred stack/reach from a bike that already fits, search within a few millimeters first, then check head angle and chainstay for handling feel. See the glossary for stack, reach, and HTA.
