Size chart for fitting. If this bike already feels right, find others with a similar riding position (size 49). Category: cyclocross.
| Size | Stack | Reach | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop |
|---|---|---|---|---|---|---|---|
| 49 | 530 mm | 375 mm | 70.5° | 75.5° | 425 mm | 1008 mm | 72 mm |
| 52 | 547 mm | 382 mm | 71.3° | 74.0° | 425 mm | 1016 mm | 72 mm |
| 54 | 560 mm | 388 mm | 71.5° | 74.0° | 425 mm | 1025 mm | 70 mm |
| 56 | 578 mm | 397 mm | 72.0° | 73.5° | 425 mm | 1036 mm | 70 mm |
| 58 | 598 mm | 405 mm | 72.3° | 73.5° | 425 mm | 1048 mm | 68 mm |
| 61 | 621 mm | 415 mm | 72.6° | 73.0° | 425 mm | 1062 mm | 68 mm |
Closest matches to this riding position — free, no login.
Stack and reach describe the frame's cockpit envelope better than traditional seat-tube sizing. If you know your preferred stack/reach from a bike that already fits, search within a few millimeters first, then check head angle and chainstay for handling feel. See the glossary for stack, reach, and HTA.
