Loading geometry
Size chart for fitting. If this bike already feels right, find others with a similar riding position (size 44). Category: road-race.
| Size | Stack | Reach | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop |
|---|---|---|---|---|---|---|---|
| 44 | 489 mm | 368 mm | 70.5° | 75.5° | 410 mm | 968 mm | 74 mm |
| 49 | 512 mm | 375 mm | 71.8° | 75.5° | 410 mm | 971 mm | 74 mm |
| 52 | 525 mm | 379 mm | 72.5° | 74.0° | 410 mm | 973 mm | 74 mm |
| 54 | 542 mm | 383 mm | 73.0° | 74.0° | 410 mm | 976 mm | 72 mm |
| 56 | 563 mm | 389 mm | 73.5° | 73.5° | 410 mm | 989 mm | 72 mm |
| 58 | 589 mm | 394 mm | 73.5° | 73.5° | 410 mm | 1004 mm | 72 mm |
| 61 | 610 mm | 398 mm | 74.0° | 73.0° | 410 mm | 1011 mm | 72 mm |
Closest matches to this riding position — free, no login.
Stack and reach describe the frame's cockpit envelope better than traditional seat-tube sizing. If you know your preferred stack/reach from a bike that already fits, search within a few millimeters first, then check head angle and chainstay for handling feel. See the glossary for stack, reach, and HTA.
