Loading geometry
Size chart for fitting. If this bike already feels right, find others with a similar riding position (size L). Category: gravel.
| Size | Stack | Reach | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop |
|---|---|---|---|---|---|---|---|
| L | 601 mm | 409 mm | 72.4° | 73.0° | 425 mm | 1049 mm | 72 mm |
| M | 561 mm | 397 mm | 72.0° | 73.5° | 425 mm | 1029 mm | 74 mm |
| ML | 581 mm | 403 mm | 72.2° | 73.2° | 425 mm | 1039 mm | 74 mm |
| S | 541 mm | 391 mm | 71.8° | 73.7° | 425 mm | 1019 mm | 74 mm |
| XL | 621 mm | 415 mm | 72.6° | 72.8° | 425 mm | 1059 mm | 72 mm |
| XS | 521 mm | 385 mm | 71.5° | 74.0° | 425 mm | 1009 mm | 74 mm |
Closest matches to this riding position — free, no login.
Stack and reach describe the frame's cockpit envelope better than traditional seat-tube sizing. If you know your preferred stack/reach from a bike that already fits, search within a few millimeters first, then check head angle and chainstay for handling feel. See the glossary for stack, reach, and HTA.
